Parent Layer: Hidden Transportation Features

Name: Hidden Bridges

Display Field: FEATURECODE

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: Bridges: All bridges are digitized as polygons. Bridges carry roads or railroads over water. Outside edges of all bridges delineated. Also bridge deck locations or clear spans where deck is not visible. This includes all overpasses (bridges that carry traffic over roads or railroads) and underpasses. Outside edge of all overpasses delineated. Bridges overlap road polygons. Pedestrian bridges are not captured. Tunnel Entrances: Entire tunnels are not captured, but all entrances to a tunnel are captured as polygons illustrating the width of the tunnel. Polygons plotted around tunnel openings and any abutments or walls which identify the tunnel entrance. Hidden Bridges: Hidden bridges are features that run under other features such as other bridges, overpasses, or tunnels and are not fully visible in an aerial photograph. The locations are interpreted based on the information visible on either side of the bridge.

Copyright Text: Office of the Chief of Technology Officer

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Effective Min Scale: 140000

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -8584584.8789091
YMin: 4691962.683908619
XMax: -8561745.824144421
YMax: 4719531.823949605
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSForwardDiagonal
Color: [168, 168, 0, 255]
Outline:
Style: esriSLSSolid
Color: [168, 168, 0, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields:

• FEATURECODE ( type: esriFieldTypeSmallInteger, alias: Feature Code , Coded Values: [1500: BRIDGE] , [1501: HIDDEN BRIDGE] , [1520: TUNNEL] , ...1 more... )
• DESCRIPTION ( type: esriFieldTypeString, alias: Description, length: 50 )
• CAPTUREACTION ( type: esriFieldTypeString, alias: Capture Action, length: 1 , Coded Values: [A: Add] , [D: Delete] , [E: Existing] , ...1 more... )
• CAPTUREDATE ( type: esriFieldTypeDate, alias: Capture Date, length: 8 )
• BRIDGE_ID ( type: esriFieldTypeString, alias: Bridge Identifier, length: 50 )
• GIS_ID ( type: esriFieldTypeString, alias: GIS Identifier, length: 50 )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
