Name: Parcel Lot Points

Display Field: SSL

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: These are lands still within the District of Columbia that has never been subdivided into either Record or Tax Lots through the two offices that manage land records (OS & RPTA), this land is referred to as Parcels, expressed as fractions (Ex Parcel 117/36). In this example, the number “36” would be the 36th out conveyance from original Parcel 117. The tracking of parcels was started in 1905 when, by Act of Congress, all the District’s unsubdivided properties which were mostly rural farms at the time were given parcel numbers. Their boundaries were also depicted (in many cases approximated), in large books in DCRA's Office of the Surveyor. Until the late 1960s, building permits were routinely issued by the city for new construction on Parcels, but today all Parcels, like Tax Lots, must be converted into subdivision Lots of Record before permits will be issued for exterior work. Parcels are only found in the old “County of Washington,” north of Florida Ave and east of the Anacostia River. There are no Parcels found within the original city limits or Georgetown. Parcels are not in Squares. There are examples where parcel land may be physically located in the middle of a city Square, but Parcels are not considered part of a Square until they are duly subdivided by the D.C. Surveyor’s Office.

Copyright Text: Department of Buildings

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 10000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -8584460.847598938
YMin: 4693413.640399576
XMax: -8561476.585333325
YMax: 4720686.146305607
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSMSCircle
Color: [190, 232, 255, 255]
Size: 4.0
Angle: 0.0
XOffset: 0
YOffset: 0
Outline:
[0, 0, 0, 255] Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields:

• CREATION_DT ( type: esriFieldTypeDate, alias: CREATION_DT, length: 8 )
• RECORDATION_DT ( type: esriFieldTypeDate, alias: RECORDATION_DT, length: 8 )
• NARRATIVE ( type: esriFieldTypeString, alias: NARRATIVE, length: 200 )
• STATUS ( type: esriFieldTypeInteger, alias: STATUS , Coded Values: [1: Current] , [2: Dead] )
• SQUARE ( type: esriFieldTypeString, alias: SQUARE, length: 50 )
• SUFFIX ( type: esriFieldTypeString, alias: SUFFIX, length: 50 )
• PAR ( type: esriFieldTypeString, alias: PAR, length: 50 )
• LOT ( type: esriFieldTypeString, alias: LOT, length: 40 )
• LOT_TYPE ( type: esriFieldTypeInteger, alias: LOT_TYPE , Coded Values: [1: Record_Lot] , [2: Tax_Lot] , [3: Air_Rights] , ...3 more... )
• KILL_DT ( type: esriFieldTypeDate, alias: KILL_DT, length: 8 )
• SSL ( type: esriFieldTypeString, alias: SSL, length: 50 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
