Name: Alley Frontage Lines

Display Field: ALLEY_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: Alley widths, street frontages, were captured during the vector property effort and reside in their own feature class. 99% of the time, these features should be coincident with the square boundary. The exceptions to this are internal alley’s that might be overlaid by a tax lot. They were captured largely to enable continuity within each square. Alley Polygon does not exist. They could be created with this data by using an automated routine which searches linear feature of the Record, Tax and Parcel Lots feature classes where Line_Classification = 3, 4 and 6, then turning these selected lines into poly’s, another method would be clipping a square boundary with the tax and record lots.

Copyright Text: Department of Buildings

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 3000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -8584254.535545932
YMin: 4695974.231580702
XMax: -8561653.264794076
YMax: 4720242.063593829
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [255, 0, 0, 255]
Width: 2
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields:

• CREATION_DT ( type: esriFieldTypeDate, alias: CREATION_DT, length: 8 )
• RECORDATION_DT ( type: esriFieldTypeDate, alias: RECORDATION_DT, length: 8 )
• NARRATIVE ( type: esriFieldTypeString, alias: NARRATIVE, length: 200 )
• EXPIRATION_DT ( type: esriFieldTypeDate, alias: EXPIRATION_DT, length: 8 )
• STATUS ( type: esriFieldTypeInteger, alias: Status , Coded Values: [1: Current] , [2: Dead] )
• SQUARE ( type: esriFieldTypeString, alias: SQUARE, length: 50 )
• SUFFIX ( type: esriFieldTypeString, alias: SUFFIX, length: 50 )
• RECORD_LENGTH_FT ( type: esriFieldTypeDouble, alias: RECORD_LENGTH_FT )
• RECORD_BEARING_DIR ( type: esriFieldTypeInteger, alias: RECORD_BEARING_DIR , Coded Values: [1: NE] , [2: NW] , [3: SE] , ...1 more... )
• RECORD_BEARING_ANGLE_DD ( type: esriFieldTypeDouble, alias: RECORD_BEARING_ANGLE_DD )
• RECORD_SPIRAL1_FT ( type: esriFieldTypeDouble, alias: RECORD_SPIRAL1_FT )
• RECORD_SPIRAL2_FT ( type: esriFieldTypeDouble, alias: RECORD_SPIRAL2_FT )
• RECORD_ARC_LENGTH_FT ( type: esriFieldTypeDouble, alias: RECORD_ARC_LENGTH_FT )
• RECORD_DELTA_ANGLE_DD ( type: esriFieldTypeDouble, alias: Record_Delta_Angle_DD )
• RECORD_RADIUS_FT ( type: esriFieldTypeDouble, alias: Record_Radius_FT )
• RECORD_MSL_FT ( type: esriFieldTypeDouble, alias: RECORD_MSL_FT )
• SURVEYED_LENGTH_FT ( type: esriFieldTypeDouble, alias: SURVEYED_LENGTH_FT )
• SURVEYED_BEARING_DIR ( type: esriFieldTypeInteger, alias: SURVEYED_BEARING_DIR , Coded Values: [1: NE] , [2: NW] , [3: SE] , ...1 more... )
• SURVEYED_BEARING_ANGLE_DD ( type: esriFieldTypeDouble, alias: SURVEYED_BEARING_ANGLE_DD )
• SURVEYED_DELTA_ANGLE_DD ( type: esriFieldTypeDouble, alias: Surveyed_Delta_Angle_DD )
• SURVEYED_RADIUS_FT ( type: esriFieldTypeDouble, alias: Surveyed_Radius_FT )
• COMPUTED_LENGTH_FT ( type: esriFieldTypeDouble, alias: COMPUTED_LENGTH_FT )
• COMPUTED_BEARING_DIR ( type: esriFieldTypeInteger, alias: COMPUTED_BEARING_DIR , Coded Values: [1: NE] , [2: NW] , [3: SE] , ...1 more... )
• COMPUTED_BEARING_ANGLE_DD ( type: esriFieldTypeDouble, alias: COMPUTED_BEARING_ANGLE_DD )
• COMPUTED_DELTA_ANGLE_DD ( type: esriFieldTypeDouble, alias: Computed_Delta_Angle_DD )
• COMPUTED_ARC_LENGTH_FT ( type: esriFieldTypeDouble, alias: Computed_Arc_Length_FT )
• COMPUTED_RADIUS_FT ( type: esriFieldTypeDouble, alias: Computed_Radius_FT )
• LINE_CLASSIFICATION ( type: esriFieldTypeInteger, alias: Line_Classification , Coded Values: [1: Street] , [2: Property] , [3: Alley] , ...5 more... )
• ALLEYLNID ( type: esriFieldTypeString, alias: ALLEYLNID, length: 50 )
• ALLEYPLYID ( type: esriFieldTypeString, alias: ALLEYPLYID, length: 50 )
• NAMED_ALLEY ( type: esriFieldTypeInteger, alias: NAMED_ALLEY , Coded Values: [1: Yes] , [0: No] )
• ALLEY_NAME ( type: esriFieldTypeString, alias: ALLEY_NAME, length: 50 )
• KILL_DT ( type: esriFieldTypeDate, alias: KILL_DT, length: 8 )
• SHAPE ( type: esriFieldTypeGeometry, alias: Shape )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: LEN )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
