View In:   ArcGIS Online Map Viewer

Name: Record Lots

Display Field: SSL

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: Record lots are defined by the Department of Buildings (DOB) – Office of the Surveyor (OS) - DC Surveyor. They are official, platted, recorded subdivision lots created by the D.C Surveyor’s Office in compliance with the Subdivision Ordinance of the District of Columbia (must have public street frontage etc). Typically, these lots are numbered 1 through 799 with no number being used more than once in a Square. Exceptions to this rule:When the 1-799 range has been exhausted within a square, the Surveyor’s Office assigns numbers from 1200 or may even use 8000 and aboveFor reasons unknown, 42 Squares have record lot numbers greater than 799 but less than 1200Additionally, in most case scenario’s, a piece of property must be a Record Lot before a building permit will be issued for that site in the District of Columbia, and all proposed Record Lots are carefully reviewed by Zoning Administration officials for compliance with the city’s Zoning Ordinances. Other agencies that review new record lots besides OS are Office of Zoning, Office of Planning, the Dept. of Public Works, Historic Preservation and DDOT.Record lots are defined only when requested by property owners, normally when they are seeking a building permit. Record lots are recorded in Plat Books and Subdivision Books in the Office of the Surveyor. These documents are bound volumes of historical representations of the locations of property lines, and they include record dimensions, though typically no bearings of lines. These lots are located within squares, which usually correspond to one or two city blocks. Certain record lots can also be classified as “of-lots”. An "Of-Lot" is the D.C. Surveyor’s Office term for describing “Remaining/Part of Original Lot X”In the record lot feature class, if a domain value of 1 resides in the “OF_LOT” field, you can assume that at one time the original lot was modified. Typically, any of these of-lots will also have a tax lot overlaying them since it is a piece or remainder of a Record Lot.

Copyright Text: Department of Buildings

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 5000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: -8584312.887998095
YMin: 4694540.208298855
XMax: -8561531.80211629
YMax: 4721082.510277542
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [130, 130, 130, 255]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 25
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: true
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: false
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field:

Fields:

• CREATION_DT ( type: esriFieldTypeDate, alias: CREATION_DT, editable: true, nullable: true, length: 8, defaultValue: null, modelName: CREATION_DT )
• RECORDATION_DT ( type: esriFieldTypeDate, alias: RECORDATION_DT, editable: true, nullable: true, length: 8, defaultValue: null, modelName: RECORDATION_DT )
• NARRATIVE ( type: esriFieldTypeString, alias: NARRATIVE, editable: true, nullable: true, length: 200, defaultValue: null, modelName: NARRATIVE )
• EXPIRATION_DT ( type: esriFieldTypeDate, alias: EXPIRATION_DT, editable: true, nullable: true, length: 8, defaultValue: null, modelName: EXPIRATION_DT )
• STATUS ( type: esriFieldTypeInteger, alias: Status, editable: true, nullable: true, defaultValue: 1, modelName: Status , Coded Values: [1: Current] , [2: Dead] )
• SQUARE ( type: esriFieldTypeString, alias: SQUARE, editable: true, nullable: true, length: 50, defaultValue: null, modelName: SQUARE )
• SUFFIX ( type: esriFieldTypeString, alias: SUFFIX, editable: true, nullable: true, length: 50, defaultValue: null, modelName: SUFFIX )
• LOT ( type: esriFieldTypeString, alias: LOT, editable: true, nullable: true, length: 40, defaultValue: null, modelName: LOT )
• LOT_TYPE ( type: esriFieldTypeInteger, alias: LOT_TYPE, editable: true, nullable: true, defaultValue: null, modelName: LOT_TYPE , Coded Values: [1: Record_Lot] , [2: Tax_Lot] , [3: Air_Rights] , ...3 more... )
• COMPUTED_AREA_SF ( type: esriFieldTypeDouble, alias: COMPUTED_AREA_SF, editable: true, nullable: true, defaultValue: null, modelName: COMPUTED_AREA_SF )
• SURVEYED_AREA_SF ( type: esriFieldTypeDouble, alias: SURVEYED_AREA_SF, editable: true, nullable: true, defaultValue: null, modelName: SURVEYED_AREA_SF )
• IS_REAR_OF ( type: esriFieldTypeInteger, alias: IS_REAR_OF, editable: true, nullable: true, defaultValue: null, modelName: IS_REAR_OF , Coded Values: [1: Yes] , [0: No] )
• BLDG_NUM ( type: esriFieldTypeInteger, alias: BLDG_NUM, editable: true, nullable: true, defaultValue: null, modelName: BLDG_NUM )
• BLDG_NUM_EXT ( type: esriFieldTypeString, alias: BLDG_NUM_EXT, editable: true, nullable: true, length: 20, defaultValue: null, modelName: BLDG_NUM_EXT )
• BLDG_NUM_END_RANGE ( type: esriFieldTypeInteger, alias: BLDG_NUM_END_RANGE, editable: true, nullable: true, defaultValue: null, modelName: BLDG_NUM_END_RANGE )
• BLDG_EXT_END_RANGE ( type: esriFieldTypeString, alias: BLDG_EXT_END_RANGE, editable: true, nullable: true, length: 40, defaultValue: null, modelName: BLDG_EXT_END_RANGE )
• QUADRANT ( type: esriFieldTypeString, alias: QUADRANT, editable: true, nullable: true, length: 40, defaultValue: null, modelName: QUADRANT )
• ZIP5 ( type: esriFieldTypeString, alias: ZIP5, editable: true, nullable: true, length: 5, defaultValue: null, modelName: ZIP5 )
• ZIP4 ( type: esriFieldTypeString, alias: ZIP4, editable: true, nullable: true, length: 4, defaultValue: null, modelName: ZIP4 )
• RECORD_AREA_SF ( type: esriFieldTypeDouble, alias: RECORD_AREA_SF, editable: true, nullable: true, defaultValue: null, modelName: RECORD_AREA_SF )
• CONV_TOLERANCE_TYPE ( type: esriFieldTypeInteger, alias: Conv_Tolerance_Type, editable: true, nullable: true, defaultValue: 1, modelName: Conv_Tolerance_Type , Coded Values: [1: Type_1] , [2: Type_2] , [3: Type_3] )
• CONV_TOLERANCE_VALUE ( type: esriFieldTypeDouble, alias: CONV_TOLERANCE_VALUE, editable: true, nullable: true, defaultValue: null, modelName: CONV_TOLERANCE_VALUE )
• CONV_TOLERANCE_RESOLUTION ( type: esriFieldTypeString, alias: CONV_TOLERANCE_RESOLUTION, editable: true, nullable: true, length: 40, defaultValue: null, modelName: CONV_TOLERANCE_RESOLUTION )
• RECORDLOTSPLYID ( type: esriFieldTypeInteger, alias: RECORDLOTSPLYID, editable: true, nullable: true, defaultValue: null, modelName: RECORDLOTSPLYID )
• PARCELSPLYID ( type: esriFieldTypeInteger, alias: PARCELSPLYID, editable: true, nullable: true, defaultValue: null, modelName: PARCELSPLYID )
• SQUAREPLYID ( type: esriFieldTypeInteger, alias: SQUAREPLYID, editable: true, nullable: true, defaultValue: null, modelName: SQUAREPLYID )
• OF_LOT_SEQ ( type: esriFieldTypeInteger, alias: Of_Lot_Seq, editable: true, nullable: true, defaultValue: 0, modelName: Of_Lot_Seq , Coded Values: [1: Yes] , [0: No] )
• BOOK_NUM ( type: esriFieldTypeString, alias: BOOK_NUM, editable: true, nullable: true, length: 40, defaultValue: null, modelName: BOOK_NUM )
• PAGE_NUM ( type: esriFieldTypeString, alias: PAGE_NUM, editable: true, nullable: true, length: 40, defaultValue: null, modelName: PAGE_NUM )
• UNDERLIES_CONDO ( type: esriFieldTypeInteger, alias: Underlies_Condo, editable: true, nullable: true, defaultValue: 0, modelName: Underlies_Condo , Coded Values: [1: Yes] , [0: No] )
• CONDO_BOOK_NUM ( type: esriFieldTypeString, alias: CONDO_BOOK_NUM, editable: true, nullable: true, length: 40, defaultValue: null, modelName: CONDO_BOOK_NUM )
• CONDO_PAGE_NUM ( type: esriFieldTypeString, alias: CONDO_PAGE_NUM, editable: true, nullable: true, length: 40, defaultValue: null, modelName: CONDO_PAGE_NUM )
• KILL_DT ( type: esriFieldTypeDate, alias: KILL_DT, editable: true, nullable: true, length: 8, defaultValue: null, modelName: KILL_DT )
• SSL ( type: esriFieldTypeString, alias: SSL, editable: true, nullable: true, length: 50, defaultValue: null, modelName: SSL )
• COL ( type: esriFieldTypeString, alias: COL, editable: true, nullable: true, length: 2, defaultValue: null, modelName: COL )
• CONDO_REGIME_NUM ( type: esriFieldTypeString, alias: CONDO_REGIME_NUM, editable: true, nullable: true, length: 50, defaultValue: null, modelName: CONDO_REGIME_NUM )
• CONDOLOT ( type: esriFieldTypeString, alias: CONDOLOT, editable: true, nullable: true, length: 1, defaultValue: null, modelName: CONDOLOT )
• Shape__Area ( type: esriFieldTypeDouble, alias: AREA, editable: false, required: true, nullable: true, defaultValue: null, modelName: SHAPE.AREA )
• Shape__Length ( type: esriFieldTypeDouble, alias: LEN, editable: false, required: true, nullable: true, defaultValue: null, modelName: SHAPE.LEN )
• MAR_ID ( type: esriFieldTypeInteger, alias: MAR_ID, editable: true, nullable: true, defaultValue: null, modelName: MAR_ID )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )

Templates:

• Name: Record Lots
  Description:
  Prototype:
  MAR_ID: null
  CREATION_DT: null
  RECORDATION_DT: null
  NARRATIVE: null
  EXPIRATION_DT: null
  STATUS: 1
  SQUARE: null
  SUFFIX: null
  LOT: null
  LOT_TYPE: null
  COMPUTED_AREA_SF: null
  SURVEYED_AREA_SF: null
  IS_REAR_OF: null
  BLDG_NUM: null
  BLDG_NUM_EXT: null
  BLDG_NUM_END_RANGE: null
  BLDG_EXT_END_RANGE: null
  QUADRANT: null
  ZIP5: null
  ZIP4: null
  RECORD_AREA_SF: null
  CONV_TOLERANCE_TYPE: 1
  CONV_TOLERANCE_VALUE: null
  CONV_TOLERANCE_RESOLUTION: null
  RECORDLOTSPLYID: null
  PARCELSPLYID: null
  SQUAREPLYID: null
  OF_LOT_SEQ: 0
  BOOK_NUM: null
  PAGE_NUM: null
  UNDERLIES_CONDO: 0
  CONDO_BOOK_NUM: null
  CONDO_PAGE_NUM: null
  KILL_DT: null
  SSL: null
  COL: null
  CONDO_REGIME_NUM: null
  CONDOLOT: null

  Drawing Tool: esriFeatureEditToolPolygon

Capabilities: Query,Extract

Sync Can Return Changes: false

Is Data Versioned: false

Supports Rollback On Failure: true

Supports ApplyEdits With Global Ids: false

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Child Resources:   Field Groups   Contingent Values

Supported Operations:   Query   Query Analytic   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata   Update Metadata
