Name: Highway Plan Lines

Display Field: NARRATIVE

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: These are lines that occurred on the city’s 1901-1905 set of master plans for all proposed roads. If a highway planning line crosses a particular property, that land cannot become a Record Lot by subdivision, even if the proposed street is no longer needed or will never be built. However there is a procedure through which a proposed road can be removed from the Highway Plan freeing up affected land for subdivision or development.

Copyright Text: Department of Buildings

Default Visibility: false

MaxRecordCount: 1000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 5000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 391456.157004297
YMin: 129228.62100759901
XMax: 407878.82700429903
YMax: 147130.0680076
Spatial Reference: 26985  (26985)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [166, 0, 25, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields:

• CREATION_DT ( type: esriFieldTypeDate, alias: CREATION_DT, length: 8 )
• RECORDATION_DT ( type: esriFieldTypeDate, alias: RECORDATION_DT, length: 8 )
• NARRATIVE ( type: esriFieldTypeString, alias: NARRATIVE, length: 200 )
• EXPIRATION_DT ( type: esriFieldTypeDate, alias: EXPIRATION_DT, length: 8 )
• STATUS ( type: esriFieldTypeInteger, alias: Status , Coded Values: [1: Current] , [2: Dead] )
• SQUARE ( type: esriFieldTypeString, alias: SQUARE, length: 50 )
• SUFFIX ( type: esriFieldTypeString, alias: SUFFIX, length: 50 )
• KILL_DT ( type: esriFieldTypeDate, alias: KILL_DT, length: 8 )
• RES ( type: esriFieldTypeString, alias: RES, length: 4 )
• PAR ( type: esriFieldTypeString, alias: PAR, length: 50 )
• LOT ( type: esriFieldTypeString, alias: LOT, length: 9 )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: SHAPE.LEN )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SHAPE ( type: esriFieldTypeGeometry, alias: Shape )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
