Name: Floodplains - General Structure

Display Field: STRUCT_ID

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: Location and attributes for flood control structures shown on the flood profile and FIRM. This table is required whenever hydraulic structures are shown in the flood profile. It is also required when channels containing the flooding are shown on the FIRM or any other structure that impacts the area’s flood risk is shown on the FIRM. This table contains both riverine and coastal structure types. Spatial elements representing general structures are represented by lines. The lines must represent the primary characteristic of the structure. For example, bridges must be represented by the transportation centerline carried by the bridge. Dams must be represented by a line corresponding to the top of the dam. A line corresponding to the centerline of the main barrel must represent a culvert.

Copyright Text: Federal Emergency Management Agency

Default Visibility: false

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -8584583.565141072
YMin: 4692089.685975698
XMax: -8561756.635265872
YMax: 4720074.078116709
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [0, 112, 255, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields:

• STRUCT_NM ( type: esriFieldTypeString, alias: Structure Name, length: 50 )
• STRUC_DESC ( type: esriFieldTypeString, alias: Structure Description, length: 254 )
• STRUCT_TYP ( type: esriFieldTypeString, alias: Structure Type, length: 60 )
• STRUCT_ID ( type: esriFieldTypeString, alias: Structure Identifier, length: 32 )
• WTR_NM ( type: esriFieldTypeString, alias: Water Name, length: 100 )
• SOURCE_CIT ( type: esriFieldTypeString, alias: Cource Citation, length: 21 )
• DFIRM_ID ( type: esriFieldTypeString, alias: Digital Flood Insurance Rate Map Identifier, length: 6 )
• VERSION_ID ( type: esriFieldTypeString, alias: Version Identifier, length: 11 )
• CST_STRUCT ( type: esriFieldTypeString, alias: Coastal Structures, length: 29 )
• LOC_DESC ( type: esriFieldTypeString, alias: Location Description, length: 254 )
• SHOWN_FIRM ( type: esriFieldTypeString, alias: Shown on Flood Insurance Rate Map, length: 1 )
• GFID ( type: esriFieldTypeString, alias: GF Identifier, length: 50 )
• GIS_ID ( type: esriFieldTypeString, alias: GIS Identifier, length: 50 )
• GLOBALID ( type: esriFieldTypeGlobalID, alias: GLOBALID, length: 38 )
• CREATED ( type: esriFieldTypeDate, alias: CREATED, length: 8 )
• EDITED ( type: esriFieldTypeDate, alias: EDITED, length: 8 )
• SHAPE ( type: esriFieldTypeGeometry, alias: Shape )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: SHAPE.LEN )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
